Industrial grade smart LTE Cat-4 modules

28. April 2021 | Planegg

Qualcomm Snapdragon chipsets

Integrated Bluetooth and Wi-Fi

Built-in Android 10.0 OS

Hot Products

SC200x series is Quectel’s  industrial grade LTE Cat 4 modules with an operational and certified built-in Android 10.0 OS. Based on Qualcomm quad-core ARM Cortex-A53 64-bit processor with built-in AdrenoTM 308 GPU, it is an ideal solution for industrial applications requiring high data rates and multimedia functions combined with a wide operation temperature range and an industrial respected long-life time. The SC200x series are available in five variants, with built-in LTE country specific and as Wi-Fi & BT only version.

This SmartModule series supports multiple-input multiple-output (MIMO) technology. The use of multiple antennas at the receiver end at the same time and on the same frequency band greatly minimizes errors and optimizes data speed. This module also combines high-speed wireless connectivity with embedded multi-constellation and high-sensitivity GNSS (GPS, BeiDou, GLONASS and Galileo) receiver for positioning which makes these modules ideal candidates for secure Point of Sales applications combining with geofencing capabilities to track the usage scenario.

A rich set of interfaces (such as LCM, Camera, Touch Panel, MIC, SPK, UART, USB, I2C and SPI) extend the applicability of the module to a wide range of M2M applications, including smart POS, smart cash registers edge device, edge computing, smart home gateways, smart robots, smart wearables, security surveillance, PDA & tablets, vending machines, delivery lockers, police and law enforcement equipment, in-car video streaming and entertainment systems, etc.

The SC200-R, the first product of the SC200 product family, is already available in the Atlantik Elektronik webshop.
